纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.077[01]) - EXHAUST MANIFOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
493 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 98414447 | [1] | EXHAUST MANIFOLD | LEC- REAR |
| 2. | 99449602 | [1] | EXHAUST MANIFOLD | LEC- FRONT |
| 3. | 98436181 | [1] | GASKET | BRE- CENTER |
| 4. | 98436180 | [2] | GASKET | BRE |
| 5. | 98424168 | [4] | SPACER | BREL=28 |
| 5. | 4861116 | [4] | SPACER | BREL=20 |
| 6. | 99460508 | [1] | SCREW | LEC |
| 6. | 98492238 | [7] | BOLT,Flng, M10 x 1.25 x 70mm | MOD |
| 7. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
| 7. | 1940149 | [1] | ENGINE TOP GASKETS KIT | LEC |
