| 1. |
413-820
|
[6] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 3. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 4. |
425-1116
|
[2] |
NUT,1"-14, G5
|
CAS
1-14 H GR 5 P Superseded by part number: 86509311
|
| 5. |
700711707
|
[2] |
CAM
|
CAS
BEARING-CAM FOLLOWER
|
| 6. |
219-17
|
[2] |
LUBE NIPPLE,3/16" NPTF
|
CAS
NIPPLE, LUBE, 3/16" x .55" lg, Drive Superseded by part number: 80722
|
| 7. |
700129529
|
[6] |
BRONZE BUSHING
|
CAS
BUSHING-BRONZE
|
| 8. |
700123293
|
[3] |
WASHER
|
CAS
|
| 9. |
85-816
|
[4] |
SET SCREW,Sq Hd, 1/2"-13 x 1"
|
CAS
1/2-13 X 1 CPSQHSS
|
| 10. |
329-148
|
[4] |
NUT,Jam, 1/2"-13, G8
|
CAS
1/2-13 HJN GR2
|
| 11. |
52324
|
[2] |
BUSHING
|
CAS
1-1/4 X 10 GAUGE NRMB Superseded by part number: 052324
|
| 12. |
495-81205
|
[2] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 13. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 14. |
700129548
|
[2] |
ARM ASSY.
|
CAS
ARM ASM.-CAM (Includes Ref: 34)
|
| 15. |
52258
|
[2] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 16. |
495-81070
|
[2] |
WASHER,1 1/32" x 1 1/2" x .120"
|
CAS
1 X 10 GAUGE NRMB Superseded by part number: 86624170
|
| 17. |
432-1640
|
[2] |
COTTER PIN,1/4" x 2 1/2"
|
CAS
Pin, Split (Cotter), 1/4" x 2 1/2" Superseded by part number: 80752
|
| 18. |
25-1316
|
[2] |
NUT,1"-14, G5
|
CAS
NUT, SLOTTED, 1"-14, G5 Superseded by part number: 86020752
|
| 19. |
413-824
|
[6] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 20. |
231-5348
|
[6] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 21. |
761312
|
[1] |
KEY
|
CAS
5/16 X 5/16 X 2-1/2 KEY
|
| 22. |
7852767
|
[4] |
RING
|
CAS
-RETAINING
|
| 23. |
700129537
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET ASM. (Includes Ref: 7)
|
| 24. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 25. |
111-360
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 26. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 27. |
700129559
|
[1] |
FINGER
|
CAS
|
| 28. |
700129555
|
[1] |
FINGER
|
CAS
WA-STUFFER
|
| 29. |
700129534
|
[1] |
SUPPORT
|
CAS
ASSEMBLY-RIGHT (Includes Ref: 7)
|
| 30. |
8746042
|
[2] |
LUBE NIPPLE
|
CAS
1/8-27 X 5-1/2 NIPPLE
|
| 31. |
217-1050
|
[2] |
90 ELBOW,1/8" - 27 NPTF Female
|
CAS
1/8 X 90 DEGREE ELBOW
|
| 32. |
219-1
|
[2] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
1/8-27 STRAIGHT ZERK Superseded by part number: 80710
|
| 33. |
700129530
|
[1] |
SHAFT ASSY.
|
CAS
SHAFT-STUFFER
|
| 34. |
D46620
|
[2] |
BEARING,31.76 mm ID x 50.81 mm OD x 23.81 mm
|
CAS
BUSHING Superseded by part number: 70668028
|
| 35. |
6201404
|
[1] |
KEY
|
CAS
5/16 X 5/16 X 3-3/4 KEY
|
| 36. |
485-13812
|
[2] |
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
|
CAS
3/8-16 X 3/4 CPSQHSS Superseded by part number: 87616
|
| 37. |
700129590
|
[1] |
CRANK
|
CAS
WA-RIGHT Superseded by part number: 85700693, 700139374, 280355
|
| 38. |
700129533
|
[1] |
SHAFT ASSY.
|
CAS
SUPPORT ASSEMBLY-LEFT (Includes Ref: 7)
|
