纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.323[01]) - PIPING - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
671 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 99480866 | [1] | RIGID TUBE | LEC- WATER OUTLET |
| 2. | 98412396 | [1] | GASKET,0.8mm Thk | MOD |
| 3. | 99472715 | [3] | HOSE | LEC |
| 4. | 13000890 | [6] | HOSE CLAMP,50mm - 70mm, Worm Gear | TTF50-70 |
| 5. | 4851424 | [1] | RIGID TUBE | LEC- WATER INLET |
| 6. | 4853480 | [1] | GASKET | BRE |
| 7. | 16043824 | [4] | SCREW,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd | TTF |
| 8. | 10519624 | [4] | WASHER,8.15mm ID x 17mm OD x 2mm Thk | TOR |
| 9. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 10. | 99450125 | [1] | RIGID TUBE | LEC- WATER INLET |
| 11. | 99451245 | [1] | PLUG | LEC |
| 12. | 11270460 | [1] | SEALING WASHER,17.2mm ID x 20.9mm OD x 1.5mm Thk | MKT |
| 13. | 99449686 | [1] | BRACKET | LEC |
| 14. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
