纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.326[01]) - THERMOSTAT - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4853501 | [1] | GASKET | BRE |
| 2. | 16043624 | [1] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | TTF |
| 3. | 15214531 | [2] | BOLT,Hex, M8 x 100mm, Cl 10.9, Full Thd | LEC Superseded by part number: 16606824 |
| 4. | 11193874 | [3] | BELLEVILLE WASHER,8.4mm ID x 16.00mm OD x 1.4mm, 1.85mm, Cl 8.8 | TTF |
| 5. | 16104121 | [2] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
| 6. | 10519624 | [4] | WASHER,8.15mm ID x 17mm OD x 2mm Thk | TOR |
| 7. | 99454061 | [1] | FLANGE | LEC |
| 8. | 4853511 | [1] | GASKET | BRE |
| 9. | 16100821 | [4] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 10. | 98420965 | [1] | HYD CONNECTOR | LEC |
| 11. | 99483771 | [1] | BODY | LEC |
| 12. | 98424854 | [1] | THERMOSTAT | TOR |
| 13. | 4863955 | [1] | SEAL | TOR Superseded by part number: 98465113 |
| 14. | 4853513 | [1] | COVER | BRE |
| 15. | 4858609 | [1] | O-RING | TTF16X22X1,5 |
| 16. | 13517521 | [1] | STUD | TOR Superseded by part number: 16729824 |
| 16. | 16994711 | [1] | PLUG | LEC |
| 17. | 16730224 | [2] | STUD | LEC |
| 17. | 13529824 | [2] | STUD | NH Superseded by part number: 16730224 |
| 18. | 76041521 | [1] | RIGID TUBE,15 mm ID, 18 mm OD, 130, 80 mm Length | LEC |
| 19. | 10182611 | [1] | BANJO BOLT,M20 x 1.5 x 36mm | MOD Superseded by part number: 10182617 |
| 20. | 98474312 | [2] | SEAL | TOR |
| 21. | 1940149 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 21. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
