纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.329[01]) - FILTER - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
181 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 1930549 | [1] | HYDRAULIC OIL FILTER | ZED-Savara Superseded by part number: 84605017 |
| 2. | 98424255 | [1] | RIGID TUBE | BRE |
| 3. | 4807728 | [1] | BODY | LEC- ASSY |
| 4. | 4807730 | [1] | HYD CONNECTOR | LEC- ASSY |
| 5. | 4864083 | [2] | BANJO BOLT,M14 x 1.5 x 30mm | TTF14X1,5 |
| 6. | 98474308 | [4] | SEALING WASHER,16mm ID x 22mm OD x 1.5mm Thk | TOR14X22X1,5 |
| 7. | 16043624 | [2] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | TTF |
| 8. | 10519624 | [2] | WASHER,8.15mm ID x 17mm OD x 2mm Thk | TOR |
| 9. | 14457681 | [1] | O-RING,0.103" Thk x 0.862" ID, -118, Cl 7, 75 Duro | TTF |
| 10. | 4807733 | [1] | SPRING | LEC |
| 11. | 14158370 | [1] | LOCK PIN,M2 x 8, Slotted | BAS |
| 12. | 4853516 | [1] | SUPPORT | BRE |
| 13. | 14458281 | [1] | O-RING,1.237" ID x 1.443" OD x 0.103" | LEC |
| 15. | 11190574 | [2] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 16. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
| 16. | 1940149 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 14. | 11234724 | [2] | BOLT,Hex, M10 x 1.25 x 45, 8.8 | TTF |
