纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.345[01]) - FAN - CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 99449114 | [1] | SUPPORT | LEC- PULLEY |
| 2. | 98427607 | [1] | BEARING | TOR |
| 3. | 15972131 | [3] | SCREW,M10 x 1.25 x 115mm | NH Superseded by part number: 15972130 |
| 3. | 11343731 | [1] | SCREW,Hex, M10 x 1.25 x 65mm, Cl 10.9 | LEC Superseded by part number: |
| 4. | 11198374 | [4] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 5. | 4722298 | [1] | COVER | LEC |
| 6. | 99456788 | [1] | PULLEY | LEC- ASSY |
| 7. | 99456800 | [1] | SET OF BELTS | LEC- BELTS |
| 8. | 16678434 | [1] | SCREW,M12 x 60mm | LEC12X60 Superseded by part number: 16678435 |
| 9. | 98427590 | [1] | WASHER | TOR12,5X58 |
| 10. | 11061976 | [1] | SNAP RING,M80, Int | TTF Superseded by part number: 16874776 |
