凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (10-028) - HYDRAULIC CYLINDER ASSEMBLY, 700715531 COMPLETE, 3-1/2 INCH BORE X 10 STROKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
B17275
|
[1] |
PISTON
|
CAS
|
| 2. |
7735087
|
[1] |
LOCK NUT
|
CAS
PISTON
|
| 3. |
8040271
|
[1] |
TUBE
|
CAS
|
| 4. |
8040263
|
[1] |
BASE
|
CAS
clevis
|
| 5. |
8040289
|
[4] |
ROD
|
CAS
TIE
|
| 6. |
7735418
|
[1] |
ROD
|
CAS
|
| 7. |
8040305
|
[1] |
HEAD (CYLINDER)
|
CAS
Superseded by part number: 84352475
|
| 8. |
427-16350
|
[2] |
CLEVIS PIN,25.4mm OD x 88.9mm L
|
IH
clevis
|
| 9. |
700715579
|
[1] |
ROD
|
CAS
clevis
|
| 10. |
432-1224
|
[2] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 11. |
B17232
|
[1] |
SEAL
|
CAS
KIT
|
