纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (1.224[02]) - TRANSMISSION OUTER CONTROLS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
566 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79107235 | [1] | CONTROL VALVE | LEC- ASSY SEE TAV.5 |
| 2. | 79092183 | [1] | BRACKET | LEC |
| 3. | 76026373 | [3] | HYDRAULIC HOSE | LEC |
| 4. | 14607870 | [1] | LOCK PIN,M8 x 70, Slotted | MKT8,5X70 Superseded by part number: 14607871 |
| 5. | 76018686 | [1] | PLATE | LEC |
| 6. | 76017729 | [1] | FLEXIBLE HOSE | LEC |
| 7. | 76030379 | [1] | FLEXIBLE HOSE | LEC |
| 8. | 76026374 | [1] | HYDRAULIC HOSE | LEC |
| 9. | 79090157 | [1] | HANDLE | LEC |
| 10. | 79090158 | [1] | BUSHING | LEC |
| 11. | 79090159 | [1] | HUB | LEC |
| 12. | 14164070 | [1] | LOCK PIN,M4 x 22, Slotted | MKT4,4X22 Superseded by part number: 14164071 |
| 13. | 79069455 | [1] | HYD CONNECTOR | LEC- ASSY |
| 14. | 70925081 | [1] | O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro | LEC Superseded by part number: 229317 |
| 15. | 79067017 | [1] | ELBOW | LEC- ASSY |
| 16. | 14437785 | [1] | O-RING,11.3mm ID x 2.4mm | LEC |
| 17. | 14306531 | [2] | HEX SOC SCREW,M8 x 1.25 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 130346A1 |
| 18. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 19. | 11106031 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | LEC |
| 20. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 21. | 12645031 | [2] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 22. | 79113969 | [1] | SENSOR | LEC |
| 23. | 79113970 | [1] | ELECTRIC CABLE | LEC |
