纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (3.437[02]) - CONTROL VALVE LINKAGE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
500 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79092887 | [1] | HUB | LEC- ASSY |
| 2. | 79084568 | [1] | BEARING ASSY,Needle, 16mm ID x 22mm OD x 14mm W | LEC |
| 3. | 79078172 | [1] | YOKE | LEC- ASSY |
| 4. | 79083329 | [1] | YOKE | LEC |
| 5. | 79111314 | [1] | ROD | LEC |
| 6. | 76032313 | [1] | TIE-ROD | LEC |
| 7. | 79078173 | [1] | PIN,16mm OD x 82mm L | LEC |
| 8. | 79078174 | [1] | PIN | LEC |
| 9. | 79081248 | [1] | BOOT | LEC |
| 10. | 79081280 | [1] | CAPPING | LEC |
| 11. | 13313417 | [4] | SCREW,Pozidriv Oval Hd, Csk, M6 x 25mm, Cl 5.8, Full Thd | IMO |
| 12. | 79090157 | [1] | HANDLE | LEC |
| 13. | 79090158 | [1] | BUSHING | LEC |
| 14. | 14164070 | [1] | LOCK PIN,M4 x 22, Slotted | MKT4,4X22 Superseded by part number: 14164071 |
| 15. | 14164370 | [2] | LOCK PIN,M4 x 30, Slotted | FOR4,4X30 |
| 16. | 11702921 | [1] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
| 17. | 79101994 | [1] | HANDLE GRIP | LEC |
| 18. | 14496631 | [3] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 19. | 11106431 | [3] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
| 20. | 79110877 | [1] | RING NUT | LEC |
