纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (2.349[01]) - TRACK CHAIN - SHOES (L=550mm) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
961 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76027939 | [1] | TRACK ASSY | LEC- ASSY Superseded by part number: 79079933 |
| 2. | 79109501 | [40] | TRACK SHOE | LEC |
| 3. | 79109502 | [1] | TRACK SHOE | LEC- MASTER |
| 4. | 76030022 | [160] | FLANGE BOLT,Hex, M20 x 1.5 x 60mm, Cl 12.9 | LEC Superseded by part number: 71401179 |
| 5. | 76030023 | [4] | FLANGE BOLT,Hex, M20 x 1.5 x 101mm, Cl 12.9 | LEC Superseded by part number: 79035815 |
| 6. | 76030024 | [160] | RING NUT | LEC |
| 7. | 79035811 | [41] | BUSHING | LEC |
| 8. | 79039325 | [41] | PIN,40.08mm OD x 220mm L | LEC |
| 9. | 79082230 | [40] | TRACK LINK | LEC- RIGHT |
| 10. | 79082231 | [40] | TRACK LINK | LEC- LEFT |
| 11. | 79082232 | [1] | CONNECTING LINK | LEC- RIGHT (SPLIT) |
| 12. | 79082233 | [1] | CONNECTING LINK | LEC- LEFT (SPLIT) |
