纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (5.646[01]) - BOTTOM GUARDS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
893 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 547737 | [3] | PLUG | LEC |
| 2. | 14604071 | [2] | SPARE PART | NH |
| 4. | 79111358 | [1] | HINGE | LEC |
| 5. | 15984134 | [22] | BOLT,Hex, M18 x 1.5 x 45mm, Cl 10.9, Full Thd | LEC |
| 6. | 79109488 | [1] | GUARD | LEC |
| 7. | 76029180 | [1] | GUARD | LEC |
| 8. | 76008985 | [1] | GUARD | LEC |
| 9. | 14496931 | [2] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 10. | 79005239 | [22] | WASHER,18.8mm ID x 41mm OD x 8mm Thk | LEC |
| 11. | 79005240 | [2] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 12. | 79078017 | [1] | GUARD | LEC |
| 13. | 79082836 | [1] | GUARD | LEC |
| 14. | 79109494 | [1] | PIN | LEC |
| 3. | 11391534 | [2] | BOLT,Hex, M16 x 1.5 x 45, 10.9, Full Thd | TTF |
