| 1. |
86633902
|
[1] |
SHIELD
|
PA
Superseded by part number: 84134271
|
| 2. |
86641496
|
[1] |
SHEAVE
|
NH
|
| 3. |
86641495
|
[1] |
SHEAVE
|
NH
|
| 12. |
65383
|
[1] |
CLIP
|
PA
Superseded by part number: 86836908
|
| 13. |
86629516
|
[1] |
SHEAVE
|
NH
|
| 14. |
86836864
|
[1] |
SPRING
|
NH
|
| 15. |
9601450
|
[1] |
SUPPORT
|
NH
|
| 21. |
86640801
|
[1] |
SPACER,13.1mm ID x 25.53mm OD x 41.27mm L
|
NH
|
| 26. |
214517
|
[1] |
PULLEY
|
PA
Superseded by part number: 86640851
|
| 27. |
86626199
|
[1] |
BALER FLYWHEEL
|
NH
|
| 28. |
86634492
|
[1] |
V-BELT,0.66" W x 115.00" L
|
NH
|
| 31. |
86640800
|
[2] |
SPACER
|
NH
|
| 32. |
291525
|
[1] |
BRACKET
|
NH
Superseded by part number: 2977092, 2977092, NH291525
|
| 40. |
87479
|
[2] |
KEY
|
NH
1/4" x 1-1/2", for 0.98" ID sheave, included in 86517694 Kit for Machines BSN 814645 Superseded by part number: GD-560
|
| 40. |
87483
|
[1] |
KEY,0.31" x 1.5" L
|
NH
5/16" x 1-1/2", for 1.00" ID sheave, included in 86517695 Kit for machines Between SN 814646 & 898625 , used on & ASN 898625
|
| 42. |
80438
|
[2] |
SET SCREW,Hex Soc, 1/4"-20 x 3/8"
|
GI
Superseded by part number: 301420S36
|
| 43. |
9626568
|
[2] |
JAM NUT,Jam, 5/16"-18, G2
|
NH
|
| 49. |
120104
|
[7] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 51. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 52. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 55. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 59. |
88971
|
[2] |
SET SCREW,5/16" - 18 x 1"
|
PA
|
| 63. |
9706693
|
[1] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 64. |
9706717
|
[1] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
NH
|
| 66. |
87364
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 67. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 68. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 106. |
120103
|
[4] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
