| 1. |
9706690
|
[8] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 2. |
86633925
|
[1] |
BRACKET
|
NH
|
| 3. |
86630099
|
[1] |
SUPPORT
|
NH
|
| 4. |
86633927
|
[1] |
COVER
|
NH
|
| 5. |
86634422
|
[1] |
ROD
|
NH
|
| 6. |
86634427
|
[1] |
HINGE
|
PA
|
| 7. |
707797
|
[2] |
HANDLE
|
PA
Superseded by part number: 264552
|
| 8. |
680067
|
[1] |
HOOK
|
NH
|
| 9. |
707795
|
[2] |
CLIP
|
PA
Superseded by part number: 264552
|
| 10. |
47325
|
[1] |
CLIP
|
NH
|
| 11. |
707796
|
[2] |
SPRING
|
PA
|
| 12. |
86633928
|
[1] |
PIN
|
NH
|
| 13. |
86630098
|
[1] |
CLAMP
|
NH
|
| 14. |
86010402
|
[1] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 15. |
44429
|
[2] |
CLAMP,9.6mm ID, 10.3mm Bolt Hole, J Type
|
NH
|
| 16. |
84821
|
[1] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| 17. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 18. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 19. |
120069
|
[2] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
|
| 20. |
120103
|
[5] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 21. |
120104
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
87362
|
[3] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
| 23. |
87016
|
[2] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 24. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 25. |
140045
|
[10] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 26. |
80684
|
[1] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 27. |
9628503
|
[1] |
NUT,3/8"-16, G5
|
NH
|
| 28. |
87304
|
[1] |
NUT,#10-24
|
BEL
|
| 30. |
100016
|
[7] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 31. |
280250
|
[1] |
COTTER PIN,3/32" OD x 3/4" L
|
NH
|
| 32. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 33. |
708115
|
[1] |
GROMMET
|
GI
|
| 34. |
255541
|
[1] |
ROD
|
PA
SPARE PART Superseded by part number: 637576
|
