凯斯零件查询(BTX11) - CASE IH BALE THROWER (1/02-) (70.280.19) - STUB AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
954 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86634473
|
[1] |
SUPPORT
|
NH
Spindle, SBX520
|
| 1. |
86634471
|
[1] |
SUPPORT
|
NH
Spindle, SBX530, SBX540 Superseded by part number: 86634472
|
| 2. |
827-12080
|
[1] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9
|
CAS
Superseded by part number: 412085
|
| 2. |
614-16050
|
[8] |
BOLT,Hex, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120090
|
| 3. |
781316
|
[8] |
WASHER,16.66mm ID x 28.45mm OD x 3.43mm Thk
|
NH
Heat Treated
|
| 4. |
832-46416
|
[8] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
