凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (005) - MAIN GEARBOX Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
849 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2126890
|
[2] |
OIL SEAL
|
R
Shaft seal ring As 100x120x12
|
| 2. |
8301522
|
[1] |
GEARBOX ASSY
|
R
Main gearbox siehe Bildtafel 5 A
|
| 3. |
8173040
|
[1] |
VALVE
|
R
Breather valve
|
| 4. |
2385331
|
[3] |
GASKET
|
R
Seal ring
|
| 5. |
2443910
|
[4] |
SCREW
|
R
Hexagonal screw M12x 95
|
| . . |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[4] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 6. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
Crank arm
|
| 7. |
933154R1
|
[2] |
SNAP RING,M80, Int
|
IH
Circlip 80x2,5 Superseded by part number: 300633
|
| 8. |
8107100
|
[1] |
COVER
|
R
|
| 9. |
800-5140
|
[2] |
SNAP RING,M40, Ext, Hvy
|
CAS
RING, SNAP, (2.5mm Thk) M40, Ext, Hvy Superseded by part number: 370006
|
| 10. |
2382802
|
[2] |
BEARING
|
R
Roller bearing 22208 E/C3-W33
|
| 11. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 13. |
2153200
|
[2] |
FELT
|
R
ring
|
| 14. |
2393910
|
[6] |
WASHER
|
R
Contact washer A16
|
| 15. |
814-16035
|
[6] |
BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86529976
|
| 16. |
2380780
|
[1] |
GASKET
|
R
Shaft seal ring B1 65x 80x 8
|
| 17. |
2443520
|
[2] |
PLUG
|
R
Locking screw
|
| 20. |
2446520
|
[1] |
FELT
|
R
ring
|
