| 1. |
8301522
|
[1] |
GEARBOX ASSY
|
R
Main gearbox
|
| 2. |
2422630
|
[19] |
SCREW
|
R
Socket head screw M12x 45
|
| 3. |
2428241
|
[19] |
CIRCLIP
|
R
Vskz 12
|
| 4. |
2126890
|
[2] |
OIL SEAL
|
R
Shaft seal ring As 100x120x12
|
| 5. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
Cy.roller bearing Ncf 2920 v
|
| 6. |
2157830
|
[2] |
GASKET
|
R
Bearing seal ring 619 20 av
|
| 7. |
8307630
|
[1] |
SPACER
|
R
Bushing
|
| 8. |
8306990
|
[1] |
GEAR
|
R
Spur gear
|
| 9. |
8307610
|
[1] |
SPACER
|
R
Bushing
|
| 10. |
8307600
|
[1] |
DRIVE SHAFT
|
R
Profile shaft
|
| 11. |
8306930
|
[1] |
HOUSING
|
R
|
| 12. |
8173040
|
[1] |
VALVE
|
R
Breather valve
|
| 13. |
2385331
|
[3] |
GASKET
|
R
Seal ring
|
| 14. |
614-10035
|
[8] |
BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 9706704
|
| 15. |
892-11010
|
[8] |
LOCK WASHER,M10
|
CAS
Spring M10 Superseded by part number: 140028
|
| 16. |
8306950
|
[1] |
HOUSING
|
R
cover
|
| 17. |
8306940
|
[1] |
HOUSING
|
R
cover
|
| 18. |
RR2157840
|
[6] |
Tensioning pin 12 x 40a
|
|
| 19. |
2136060
|
[1] |
SHIM
|
R
s 2,0 mm
|
| 19. |
R2159321
|
[1] |
SHIM
|
R
s 1,0 mm
|
| 19. |
2157852
|
[1] |
SHIM
|
R
s 0,5 mm
|
| 19. |
2157862
|
[1] |
SHIM
|
R
s 0,3 mm
|
| 19. |
2157872
|
[1] |
SHIM
|
R
s 0,1 mm
|
| 20. |
2157810
|
[1] |
BEARING
|
R
Ta.roller bearing 332 16
|
| 21. |
931720R1
|
[16] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8
|
IH
Hexagonal screw M 10x40 Superseded by part number: 86508581
|
| 22. |
8311220
|
[1] |
GEAR-SET
|
R
Bevel gear set mit Pos. 41
|
| 23. |
8306980
|
[1] |
PINION
|
R
shaft
|
| 24. |
933286R1
|
[1] |
SNAP RING,M75, Int
|
IH
Circlip I 75x2,5 Superseded by part number: 382103
|
| 25. |
8131691
|
[1] |
COVER
|
R
|
| 26. |
8131801
|
[1] |
SHIM
|
R
s 0,9 mm
|
| 26. |
8131790
|
[1] |
SHIM
|
R
0,8 mm
|
| 26. |
8131780
|
[1] |
SHIM
|
R
0,6 mm
|
| 26. |
8131770
|
[1] |
SHIM
|
R
0,5 mm
|
| 26. |
8131761
|
[1] |
SHIM
|
R
s 0,15 mm
|
| 27. |
2436950
|
[1] |
BEARING
|
R
Ta.roller bearing 313 10
|
| 28. |
8131740
|
[1] |
SPACER
|
R
Ring
|
| 29. |
2394490
|
[1] |
WASHER
|
R
Back-up washer
|
| 30. |
2380750
|
[1] |
BEARING
|
R
Ta.roller bearing 320 09x
|
| 31. |
2358060
|
[2] |
NUT
|
R
Slotted nut M45x1,5
|
| 32. |
2380760
|
[1] |
PLATE, LOCKING
|
R
Locking plate A 45
|
| 33. |
2380780
|
[1] |
GASKET
|
R
Shaft seal ring B1 65x 80x 8
|
| 34. |
2440540
|
[1] |
GASKET
|
R
O-ring 36x9 n
|
| 35. |
8085841
|
[1] |
HUB
|
R
Coupler mit Pos. 36
|
| 36. |
08075771
|
[1] |
HALF-BUSHING
|
R
Shear bush
|
| 37. |
2150090
|
[10] |
SCREW
|
R
Hexagonal screw M 8x1 x25
|
| . . |
235132.1
|
[10] |
Spring washer 8
|
|
| . . |
2361720
|
[1] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| 39. |
933030R1
|
[1] |
SNAP RING,M55, Ext
|
IH
Circlip 55x2 Superseded by part number: 327911
|
| 40. |
2394460
|
[1] |
BEARING
|
R
Cy.roller bearing Nup 2211v
|
| 42. |
8307620
|
[1] |
SPACER
|
R
Bushing
|
| 43. |
8306970
|
[1] |
COVER
|
R
Housing cover
|
| 44. |
2126410
|
[1] |
SPACER
|
R
Inner ring Ir 90x100x30
|
| 45. |
2443520
|
[2] |
PLUG
|
R
Locking screw
|
| 46. |
R39851
|
[1] |
BEARING
|
P
Ta.roller bearing 322 16
|
| 47. |
8306960
|
[1] |
COVER
|
R
Housing cover
|
| 49. |
614-10030
|
[16] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
