凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (006) - ANGLE DRIVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
571 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
931537R1
|
[2] |
BOLT,Hex, M10 x 1.5 x 85mm, Cl 8.8
|
IH
Hexagonal screw M10x 85 Superseded by part number: 87015575
|
| . . |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[2] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 2. |
614-12040
|
[6] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 3. |
239389N0
|
[6] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 4. |
8306230
|
[1] |
WASHER
|
R
|
| 5. |
2121130
|
[1] |
GASKET
|
R
Shaft seal ring Ba 50x 90x10
|
| 6. |
8173040
|
[1] |
VALVE
|
R
Breather valve
|
| 7. |
2385331
|
[3] |
GASKET
|
R
Seal ring
|
| 8. |
8300311
|
[1] |
GEARBOX ASSY
|
R
Angle drive siehe Bildtafel 6 A
|
| 9. |
2157880
|
[2] |
OIL SEAL
|
R
Shaft seal ring A 70x 90x10
|
| 10. |
8303260
|
[1] |
CRANK
|
R
|
| 11. |
8300780
|
[1] |
SPACER
|
R
Bushing
|
| 14. |
614-12020
|
[1] |
BOLT,Hex, M12 x 1.75 x 20mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43151
|
| 15. |
2443520
|
[2] |
PLUG
|
R
Locking screw
|
| 16. |
8192870
|
[2] |
DRIVE SPROCKET
|
R
Sprocket 25,4 Tlg 16Z
|
| 17. |
2344520
|
[2] |
CIRCLIP
|
R
|
| 18. |
8192840
|
[1] |
CHAIN (AG)
|
R
Roller chain 16B-2x 16 E
|
| . . |
8192850
|
[1] |
DRAG LINK
|
R
Chain lock E-16B-2
|
| 19. |
2335750
|
[6] |
WASHER
|
R
13 x 40 x3
|
