| 1. |
374889
|
[2] |
BOLT,Hex, M16 x 100mm, Cl 8.8
|
NH
BOLT, Hex, M16 x 100, 8.8
|
| . . |
2380470
|
[2] |
NUT
|
R
Securing nut Vm16
|
| . . |
2393910
|
[2] |
WASHER
|
R
Contact washer A16
|
| 2. |
830322.3
|
[2] |
Crank, Start Serial: 04400025
|
|
| 2. |
8300790
|
[2] |
CRANK
|
R
, Serial Range: -04400024
|
| 3. |
2138250
|
[1] |
SCREW
|
R
Threaded pin M10x1,25x 8, - auf Ausfuhr. achten
|
| 3. |
2365520
|
[1] |
SET SCREW
|
R
Threaded pin M10x 8, - auf Ausfuhr. achten
|
| 4. |
2339771
|
[1] |
RING
|
R
Tension ring 50
|
| 5. |
1408742R1
|
[2] |
FLANGED BEARING
|
IH
Metal flange Fb 210
|
| 6. |
2339760
|
[1] |
BEARING ASSY
|
R
Lock collar bear. Bohrungsd. 50 Superseded by part number: 754393
|
| 7. |
2334540
|
[4] |
SCREW
|
R
Flat head bolt M12x 25x14
|
| . . |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[4] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 8. |
8300330
|
[1] |
DRIVE SHAFT
|
R
Feeder shaft D 50x1303,5
|
| 9. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
Shaft seal ring As 65x 90x10
|
| 10. |
930145R1
|
[4] |
BOLT,Hex, M16 x 2 x 70mm, Cl 8.8
|
IH
Superseded by part number: 120092
|
| 12. |
8173040
|
[1] |
VALVE
|
R
Breather valve
|
| 13. |
2381470
|
[2] |
GASKET
|
R
Seal ring
|
| 14. |
2443520
|
[1] |
PLUG
|
R
Locking screw
|
| 15. |
2157880
|
[1] |
OIL SEAL
|
R
Shaft seal ring A 70x 90x10
|
| 16. |
8300321
|
[1] |
GEARBOX ASSY
|
R
Angle drive siehe Bildtafel 7 A
|
| 17. |
2392430
|
[1] |
PLUG
|
R
Locking screw M18x1,5
|
| 18. |
2343560
|
[1] |
WASHER
|
R
, Serial Range: -04400304
|
| 19. |
614-10025
|
[1] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
, Start Serial: 04400595 Superseded by part number: 11106231
|
| . . |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: 04400595
|
| . . |
98-029441
|
[1] |
WASHER
|
FO
Contact washer A10, Start Serial: 04400595 Superseded by part number: 140045
|
| 20. |
614-8025
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
, Start Serial: 04400595 Superseded by part number: 43127
|
| . . |
43362
|
[1] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10, Start Serial: 04400595
|
| . . |
98-029447
|
[1] |
WASHER
|
FO
Contact washer A 8, Start Serial: 04400595 Superseded by part number: 322358
|
| 21. |
8311560
|
[1] |
SUPPORT
|
R
, Start Serial: 04400595
|
