凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (013) - KNOTTER SHAFT CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
595 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2376081
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 6 x 70
|
| 2. |
2376142
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 10 x 70
|
| 3. |
8303670
|
[1] |
BUSHING
|
R
Adjusting ring
|
| 4. |
933286R1
|
[2] |
SNAP RING,M75, Int
|
IH
Circlip 75x2,5 Superseded by part number: 382103
|
| 5. |
2385390
|
[2] |
BEARING
|
R
Grvd.ball bearing 6009-2RS
|
| 6. |
2383870
|
[1] |
WASHER
|
R
Back-up washer S 45x 55
|
| 7. |
8303130
|
[1] |
GEAR
|
R
Clutch wheel mit Pos. 19, 20
|
| 8. |
8303150
|
[1] |
PLATE ASSY.
|
R
Clutch ring cpl mit Pos. 9, 10,20
|
| 9. |
2370550
|
[1] |
RIVET
|
R
Countersunk rivet 6 x40
|
| 10. |
0021292
|
[1] |
CAM
|
R
|
| 11. |
8303170
|
[1] |
CLUTCH
|
R
complete
|
| 12. |
0021623
|
[1] |
PIN
|
R
|
| 13. |
2369420
|
[1] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 15. |
0021360
|
[1] |
SPRING
|
R
|
| 16. |
0008931
|
[1] |
LEVER
|
R
Fall lever
|
| 17. |
2368950
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 6,5x 36
|
| 18. |
932231R1
|
[1] |
LOCK PIN,M4 x 36, Slotted
|
IH
Tensioning pin 4 x 36 Superseded by part number: 9510330
|
| 20. |
08075771
|
[2] |
HALF-BUSHING
|
R
Shear bush
|
| 21. |
814-8045
|
[1] |
BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8
|
CAS
Superseded by part number: 16044124
|
| . . |
2381320
|
[1] |
NUT
|
R
Securing nut VM 8 Superseded by part number: 86528579
|
| . . |
98-029447
|
[1] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 22. |
2391720
|
[1] |
WASHER
|
R
Back-up washer S100x120
|
| 23. |
800-11100
|
[1] |
SNAP RING,M100, Ext
|
CAS
Circlip 100x3 Superseded by part number: 370010
|
