凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (014) - KNOTTER SHAFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
275 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
931720R1
|
[2] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8
|
IH
Hexagonal screw M12x 90 Superseded by part number: 86508581
|
| 2. |
2351242
|
[2] |
WASHER
|
R
13
|
| 3. |
238234N0
|
[2] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 4. |
8303290
|
[2] |
CRANK
|
R
|
| 5. |
5602140
|
[4] |
FLANGE
|
R
Metal flange Bf 80
|
| 6. |
5602121
|
[2] |
BEARING
|
R
Lock collar bear. Pea 208-2S
|
| 7. |
2365520
|
[4] |
SET SCREW
|
R
Threaded pin M10x 8
|
| 8. |
5602130
|
[2] |
BUSHING
|
R
Tension ring 40
|
| 9. |
2376081
|
[8] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 6 x 70
|
| 10. |
2376142
|
[8] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 10 x 70
|
| 11. |
8303030
|
[1] |
DRIVE SHAFT
|
R
Knot shaft D 50x1150
|
| 12. |
614-12025
|
[8] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 300388
|
| . . |
2361720
|
[8] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[8] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 13. |
614-10025
|
[2] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| . . |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[2] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 15. |
614-8025
|
[6] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[6] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[6] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 16. |
8166973
|
[1] |
BRAKE DISC
|
R
|
| 17. |
8166983
|
[1] |
HUB
|
R
|
| 18. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
Cam track Disc
|
| 20. |
8135690
|
[1] |
SPRING
|
R
Flat spring
|
| 21. |
2364750
|
[2] |
SCREW
|
R
Flat head bolt M 6x 16x10
|
| . . |
825-1406
|
[2] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[2] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 22. |
8166514
|
[4] |
CAM
|
R
Knotter disk
|
| 23. |
8085461
|
[2] |
BRAKE LINING
|
R
|
| 24. |
2379501
|
[8] |
RIVET
|
R
A 4,8x12
|
| 26. |
0000170
|
[2] |
SPRING
|
R
Compress.spring
|
| 27. |
8085412
|
[1] |
SUPPORT
|
R
|
| 28. |
8085472
|
[1] |
RETAINER
|
R
Brake plate mit Pos. 23, 24
|
| 29. |
8085442
|
[1] |
RETAINER
|
R
Brake plate mit Pos. 23, 24
|
| 30. |
2364640
|
[2] |
SCREW
|
R
Flat head bolt M10x 70
|
