凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (065) - HYDRAULIC CYLINDER (VAR.9047), FOR HYDRAULIC BRAKE SYSTEM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
387 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8169950
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 2. |
8169990
|
[1] |
PISTON ROD
|
R
Plunger
|
| 3. |
2152630
|
[1] |
GASKET
|
R
Wiper seal 25x35x 7
|
| 4. |
2152610
|
[3] |
RING, SNAP
|
R
Snap ring B 33
|
| 5. |
0794950
|
[2] |
SPACER
|
R
Bushing
|
| 6. |
2390090
|
[1] |
BUSHING
|
R
Lip seal
|
| 7. |
0795021
|
[1] |
WASHER
|
R
Back-up ring
|
| 8. |
0794900
|
[1] |
WASHER, THRUST
|
R
Thrust washer
|
| 9. |
2394240
|
[1] |
RING, SNAP
|
R
Snap ring A 25
|
| 10. |
8169960
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 11. |
2387120
|
[1] |
UNION
|
R
Screw-in union L10B-M
|
