凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (066) - HYDRAULIC LINES, FOR PICK-UP LIFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
175 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6722090
|
[3] |
CLAMP
|
R
Attaching clamp
|
| 2. |
6071100
|
[3] |
SHIN
|
R
Rubber bearing
|
| 3. |
8304681
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 4. |
2387180
|
[2] |
UNION
|
R
Connect.union L 8
|
| 5. |
6026211
|
[1] |
HOSE
|
R
pipe
|
| 6. |
2114890
|
[3] |
O-RING
|
R
6 x1,5
|
| 7. |
2387880
|
[1] |
UNION
|
R
Angle union L 8
|
| 8. |
8161522
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder siehe Bildtafel 67
|
| 9. |
8304701
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 10. |
6072530
|
[1] |
BAFFLE
|
R
Screen
|
| 11. |
6898460
|
[1] |
HOSE
|
R
pipe
|
| 12. |
6836590
|
[1] |
CYLINDER END CAP
|
R
Rubber bearing
|
| 14. |
6836580
|
[3] |
SHIN
|
R
Rubber bearing
|
| 15. |
6832540
|
[3] |
COLLAR CLAMP
|
R
Attaching clamp
|
| 16. |
6978010
|
[1] |
COCK
|
R
Ball-type tap
|
| 17. |
8175180
|
[1] |
SPACER
|
R
Threaded bushing
|
| 18. |
6335330
|
[1] |
GASKET
|
R
Seal ring
|
| 19. |
6898670
|
[1] |
UNION
|
R
Coupling Dn 6, mit Position 20
|
| 20. |
8129900
|
[1] |
PROTECTOR
|
R
Dust cap
|
