凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (067) - HYDRAULIC CYLINDER, FOR PICK-UP LIFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
396 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8161522
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 2. |
8168980
|
[1] |
PISTON ROD
|
R
Plunger
|
| 3. |
2390220
|
[1] |
WIPER SEAL
|
R
Mud scraper
|
| 4. |
2338230
|
[3] |
CLIP
|
R
Snap ring B 30
|
| 5. |
0794930
|
[2] |
SPACER
|
R
Bushing
|
| 6. |
6561140
|
[1] |
GASKET
|
R
Lip seal
|
| 7. |
0795011
|
[1] |
WASHER
|
R
Back-up ring
|
| 8. |
0794880
|
[1] |
WASHER, THRUST
|
R
Thrust washer
|
| 9. |
2390210
|
[1] |
RING, SNAP
|
R
Snap ring A 20
|
| 10. |
8161541
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 11. |
6568150
|
[1] |
VALVE POPPET
|
R
Non-return valve mit Position 12, 13
|
| 12. |
6568160
|
[1] |
BAFFLE
|
R
Screen
|
| 13. |
2390420
|
[1] |
RING
|
R
Snap ring B 7
|
| 14. |
238234N0
|
[2] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 15. |
2351242
|
[2] |
WASHER
|
R
13
|
| 16. |
931492R1
|
[2] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
IH
Hexagonal screw M12x 50 Superseded by part number: 9706702
|
