凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (068) - HYDRAULIC LINES (VAR.9040), HYDRAULIC DENSITY CONTROL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
479 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2392650
|
[1] |
TEE
|
R
T-union L 8
|
| 2. |
6072530
|
[1] |
BAFFLE
|
R
Screen
|
| 3. |
2387890
|
[1] |
UNION
|
R
T-union support L 8
|
| 4. |
4060821
|
[1] |
OLIVE
|
R
Nipple
|
| 5. |
7507841
|
[1] |
NUT
|
R
Overthrow nut
|
| 6. |
8306480
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 7. |
8306460
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 8. |
2387180
|
[2] |
UNION
|
R
Connect.union L 8
|
| 9. |
2114890
|
[4] |
O-RING
|
R
6x1,5
|
| 10. |
6722090
|
[1] |
CLAMP
|
R
Attaching clamp
|
| 11. |
6836590
|
[1] |
CYLINDER END CAP
|
R
Rubber bearing
|
| 12. |
6898460
|
[2] |
HOSE
|
R
pipe
|
| 13. |
6898670
|
[2] |
UNION
|
R
Coupling Dn 6, mit Position 14
|
| 14. |
8129900
|
[2] |
PROTECTOR
|
R
Dust cap
|
