凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (069) - HYDRAULIC LINES (VAR.9040), HYDRAULIC DENSITY CONTROL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
726 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8306500
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder siehe Bildtafel 71
|
| 2. |
2386930
|
[1] |
UNION
|
R
Angle union L10 Superseded by part number: 190003551459
|
| 3. |
6836590
|
[1] |
CYLINDER END CAP
|
R
Rubber bearing
|
| 4. |
6722090
|
[1] |
CLAMP
|
R
Attaching clamp
|
| 5. |
6898450
|
[2] |
HOSE
|
R
pipe
|
| 6. |
8306400
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 7. |
6437070
|
[1] |
VALVE
|
R
Arrest.block ass. siehe Bildtafel 70
|
| 8. |
2114890
|
[2] |
O-RING
|
R
6 x1,5
|
| 9. |
6832540
|
[6] |
COLLAR CLAMP
|
R
Attaching clamp
|
| 10. |
6836580
|
[6] |
SHIN
|
R
Rubber bearing
|
| 11. |
7138451
|
[1] |
SUPPORT
|
R
angle 25x5x130
|
| 12. |
8306421
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 13. |
8306441
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 14. |
7507841
|
[1] |
NUT
|
R
Overthrow nut
|
| 15. |
4060821
|
[1] |
OLIVE
|
R
Nipple
|
