凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (071) - HYDRAULIC CYLINDERS (VAR.9040), HYDRAULIC DENSITY CONTROL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1000 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8306500
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 2. |
6430410
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder
|
| 3. |
5734710
|
[1] |
JACK PISTON
|
R
Piston nut
|
| 4. |
2390290
|
[2] |
GASKET
|
R
Lip seal
|
| 5. |
5734700
|
[1] |
JACK PISTON
|
R
Plunger
|
| 6. |
5734690
|
[1] |
COLLAR
|
R
Spacer window
|
| 7. |
6430451
|
[1] |
PISTON ROD
|
R
|
| 8. |
6563060
|
[1] |
GASKET
|
R
O-ring 58 x3 -N
|
| 9. |
2390730
|
[1] |
WASHER
|
R
Back-up ring
|
| 10. |
5734671
|
[1] |
CLIP
|
R
Securing wire
|
| 11. |
5734662
|
[1] |
TRANSMISSION SLEEVE
|
R
Cylinder head
|
| 12. |
2390090
|
[1] |
BUSHING
|
R
Lip seal
|
| 13. |
2390080
|
[1] |
SEGMENT
|
R
Mud scraper Superseded by part number: 239008N0
|
| 14. |
525-5111
|
[1] |
NUT,M22 x 1.5, Cl 8
|
IH
Hexagonal nut M22x1,5
|
| 15. |
8306510
|
[1] |
UNION
|
R
Threaded connect.
|
| 16. |
2387120
|
[2] |
UNION
|
R
Screw-in union L10B-M
|
