凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (039) - MECHANICAL ADJUSTMENT OF BALE DENSITY (VAR.9039), UP TO MACHINE NR. 04400304 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
732-4028
|
[4] |
COTTER PIN,M4 x 28
|
CAS
Split pin 4 x 28
|
| 2. |
2369480
|
[4] |
WASHER
|
R
|
| 3. |
8302850
|
[2] |
TRANSMITTER
|
R
Shaft Superseded by part number: R8302850
|
| 4. |
8302732
|
[1] |
HATCH, ASSY.
|
R
Door top
|
| 5. |
8302820
|
[1] |
HATCH, ASSY.
|
R
Door bottom -
|
| 6. |
2381781
|
[2] |
ARRESTER
|
R
Ball holder Star, -
|
| 7. |
2333230
|
[4] |
NUT
|
R
Securing nut Vm12
|
| 8. |
8086901
|
[2] |
HANDLE
|
R
|
| 9. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
Pin
|
| 10. |
2383680
|
[4] |
HANDLE
|
R
Ball knob
|
| 11. |
8302841
|
[4] |
SPRING
|
R
Tension spring
|
| 12. |
8302900
|
[2] |
SUPPORT
|
R
Strap -
|
| 14. |
932234R1
|
[4] |
LOCK PIN,M6 x 40, Slotted
|
IH
Superseded by part number: 300869
|
| 15. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1, - Superseded by part number: 321204
|
