凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (040) - HYDRAULIC ADJUSTMENT OF BALE DENSITY (VAR.9040) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
988 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
732-4028
|
[4] |
COTTER PIN,M4 x 28
|
CAS
Split pin 4 x 28
|
| 2. |
2369480
|
[4] |
WASHER
|
R
|
| 3. |
R8302850
|
[2] |
ROD
|
R
Shaft
|
| 4. |
8306102
|
[1] |
HATCH, ASSY.
|
R
Pressure flap
|
| 5. |
8302732
|
[1] |
HATCH, ASSY.
|
R
Door top
|
| 6. |
108644
|
[6] |
SEAT
|
IH
Split pin 5 x 36 Superseded by part number: NLS
|
| 7. |
5012820
|
[6] |
WASHER
|
R
|
| 8. |
2339600
|
[6] |
PIN
|
R
B22H11x70x60
|
| 9. |
8306121
|
[2] |
LEVER ASSY.
|
R
Reversing lever
|
| 10. |
8306331
|
[2] |
SUPPORT
|
R
Strap
|
| 11. |
8302841
|
[4] |
SPRING
|
R
Tension spring
|
| 12. |
7912090
|
[3] |
MUDFLAP
|
R
Floor covering
|
