凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (041) - BALE CHAMBER TENSION INDICATOR (VAR.9040) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-6020
|
[3] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[3] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[3] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 2. |
05030510
|
[2] |
RING
|
R
Adjusting ring
|
| 3. |
2363250
|
[2] |
AXLE PIN
|
R
Threaded pin M 8x10
|
| 4. |
8004312
|
[1] |
CYLINDER END CAP
|
R
Plastic bearing
|
| 5. |
2369420
|
[1] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 6. |
4092320
|
[2] |
CLAMP
|
R
Wire rope clamp 1/8
|
| 7. |
8306140
|
[1] |
ROPE
|
R
5300Lg
|
| 8. |
6592620
|
[1] |
VALVE SPRING
|
R
Tension spring
|
| 9. |
5147580
|
[1] |
ADHESIVE
|
R
Sticker
|
| 10. |
8174891
|
[1] |
SEGMENT
|
R
|
| 11. |
8306240
|
[1] |
SUPPORT
|
R
Strap
|
| 12. |
614-8020
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
239393N1
|
[2] |
WASHER
|
FO
Contact washer B 8 Superseded by part number: 322358
|
| 13. |
930111R1
|
[2] |
BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8
|
IH
Hexagonal screw M10x 45, (1) Superseded by part number: 56614
|
| . . |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
(1) M10, Cl 8
|
| . . |
98-029441
|
[2] |
WASHER
|
FO
Contact washer A10, (1) Superseded by part number: 140045
|
| 14. |
9657080
|
[2] |
SPACER
|
R
bush (1)
|
| 15. |
9656930
|
[2] |
SHIFTER ROLLER
|
R
Cable roller (1)
|
| 16. |
9031560
|
[2] |
GUIDE
|
R
Rip cord guide (1)
|
