纽荷兰零件查询(FD20) - CRAWLER DOZER (L3.08[001]) - ROPS CANOPY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11112231. | 11112231 | [12] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 11112631. | 11112631 | [4] | BOLT,Hex, M12 x 35mm, Cl 10.9 | LECBOLT, Hex, M12 x 35, 10.9 Superseded by part number: 626-12035 |
| 76004660. | 76004660 | [1] | SHIELD | LEC |
| 76004666. | 76004666 | [1] | SHIELD | LEC |
| 76004667. | 76004667 | [1] | SHIELD | LEC |
| 79005242. | 79005242 | [16] | WASHER,12.6mm ID x 28mm OD x 7mm Thk | LEC |
| 79019838. | 79019838 | [2] | GASKET | LECSHAPED BAR |
| 79019938. | 79019938 | [4] | PAD | LECSMALL BLOCK |
| 79019939. | 79019939 | [2] | PAD | LECSMALL BLOCK |
| 79027270. | 79027270 | [1] | SHIELD | LEC |
| 79027278. | 79027278 | [1] | GRILLE | LECSHIELD |
| 79027279. | 79027279 | [1] | GRILLE | LECSHIELD |
| 79027280. | 79027280 | [1] | BRACKET | LEC |
