凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (047) - TOOL BOX, CHAIN GUARD Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8305682
|
[1] |
SHEET
|
R
Chain guard
|
| 2. |
5601350
|
[1] |
PLUG
|
R
Locking plug
|
| 3. |
8049510
|
[1] |
FASTENER
|
R
Hood holder
|
| 4. |
732-5032
|
[1] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 32
|
| 5. |
6877470
|
[2] |
STOP
|
R
Rubber pad
|
| 6. |
6100971
|
[6] |
SCREW
|
R
Flat head bolt M 8x 16
|
| . . |
43362
|
[6] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[6] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 7. |
8305671
|
[1] |
SHEET
|
R
Chain guard
|
| 8. |
6100991
|
[4] |
SCREW
|
R
Flat head bolt M 8x 25
|
| 9. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
239393N1
|
[4] |
WASHER
|
FO
Contact washer B 8 Superseded by part number: 322358
|
| 10. |
8305711
|
[1] |
BOX
|
R
|
| 11. |
614-6016
|
[8] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| . . |
825-1406
|
[8] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[8] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 12. |
6543130
|
[2] |
HINGE
|
R
|
| 13. |
8305760
|
[1] |
COVER
|
R
|
