纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04[002A]) - TRANSMISSION GEARS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
470 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10334510. | 10334510 | [1] | PIN | LEC |
| 11071376. | 11071376 | [4] | SNAP RING,M90, Ext | LECRING, RETAINING, M90, Ext Superseded by part number: 300639 |
| 14161470. | 14161470 | [4] | LOCK PIN,M3 x 10, Slotted | MODPIN Superseded by part number: 83981435 |
| 14254631. | 14254631 | [1] | SCREW,M14 x 1.5 x 40mm | MKT |
| 14471380. | 14471380 | [1] | O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro | TTF-330, 70 Duro, 2.1" ID x .210" Thk Superseded by part number: 235760 |
| 20063010. | 20063010 | [1] | BALL | LEC |
| 20063400. | 20063400 | [1] | BALL,11.91mm OD | FOR |
| 20063500. | 20063500 | [1] | BALL,12.7mm OD | TTF |
| 70033063. | 70033063 | [1] | SPARE PART | CMILOCKRING |
| 70639547. | 70639547 | [4] | ROLLER BEARING,76.19mm ID x 85.77mm OD x 25.4mm W | CMIBEARING |
| 70699049. | 70699049 | [4] | SPACER | CMIWASHER |
| 73037597. | 73037597 | [4] | THRUST BEARING | CMIBEARING Superseded by part number: A75158 |
| 73037598. | 73037598 | [4] | WASHER | CMI |
| 79004270. | 79004270 | [1] | CYLINDRICAL ROLLER BEARING,65mm ID x 120mm OD x 31mm W | LECBEARING |
| 79004271. | 79004271 | [1] | BALL BEARING,65mm ID x 140mm OD x 33mm W | LECBEARING |
| 79017819. | 79017819 | [4] | RING | LEC Superseded by part number: 79060609 |
| 79026141. | 79026141 | [1] | DRIVE BUSHING | LECDRAG SLEEVE |
| 79030941. | 79030941 | [1] | SPACER | LEC |
| 79030942. | 79030942 | [1] | SPACER | LEC |
| 79030943. | 79030943 | [1] | WASHER | LEC |
| 79040283. | 79040283 | [1] | SHAFT | LEC Superseded by part number: 79052509 |
| 79040340. | 79040340 | [2] | RING,82mm ID x 90mm OD x 2.38mm Thk | LEC |
| 79045810. | 79045810 | [1] | KIT | LEC-CONSISTING OF |
| 79052509. | 79052509 | [1] | SHAFT | LEC |
| 79060609. | 79060609 | [4] | SEALING RING,57.5mm ID x 65.12mm OD x 2.38mm Thk | LEC |
