纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04[003]) - TRANSMISSION GEARS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
742 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11071376. | 11071376 | [2] | SNAP RING,M90, Ext | LECRING, RETAINING, M90, Ext Superseded by part number: 300639 |
| 14161470. | 14161470 | [4] | LOCK PIN,M3 x 10, Slotted | MODDOWEL Superseded by part number: 83981435 |
| 14246210. | 14246210 | [1] | PLATE | LECCLIP |
| 14274331. | 14274331 | [3] | SCREW,M12 x 1.25 x 20mm | LEC |
| 14464381. | 14464381 | [1] | O-RING,47.22mm ID x 2.137" OD x 3.53mm | LEC-225, Cl 7, 1.859" ID x .139" Thk Superseded by part number: 17289781 |
| 14606870. | 14606870 | [1] | LOCK PIN,M8 x 28, Slotted | LECPIN Superseded by part number: |
| 20063500. | 20063500 | [1] | BALL,12.7mm OD | TTF |
| 70191026. | 70191026 | [1] | SPACER | CMILOCKRING |
| 70639547. | 70639547 | [4] | ROLLER BEARING,76.19mm ID x 85.77mm OD x 25.4mm W | CMIBEARING |
| 70688799. | 70688799 | [4] | SPACER | CMILOCKRING |
| 70695625. | 70695625 | [1] | PIN | CMI |
| 70699049. | 70699049 | [6] | SPACER | CMIWASHER |
| 70915904. | 70915904 | [1] | BALL | CMI Superseded by part number: 86642304 |
| 70933063. | 70933063 | [1] | RING | CMILOCKRING |
| 73037597. | 73037597 | [6] | THRUST BEARING | CMIBEARING Superseded by part number: A75158 |
| 73037598. | 73037598 | [3] | WASHER | CMI |
| 73037656. | 73037656 | [1] | ROLLER BEARING,3" ID x 3.3769" OD | CMIBEARING Superseded by part number: 1-2273 |
| 73037674. | 73037674 | [2] | RING | CMI |
| 73114791. | 73114791 | [1] | LOCKING RING | CMITHREADED RING |
| 79003383. | 79003383 | [1] | GEAR | LECDRIVEN GEAR |
| 79003398. | 79003398 | [1] | GEAR | LECDRIVEN GEAR |
| 79004270. | 79004270 | [2] | CYLINDRICAL ROLLER BEARING,65mm ID x 120mm OD x 31mm W | LECBEARING |
| 79012151. | 79012151 | [1] | FLANGE | LEC |
| 79017819. | 79017819 | [4] | RING | LEC Superseded by part number: 79060609 |
| 79018318. | 79018318 | [1] | SHAFT | LEC Superseded by part number: 79020348, 79020215, 79020213, 79018906, 79020214 |
| 79018321. | 79018321 | [2] | RING | LECLOCKRING |
| 79018906. | 79018906 | [2] | SCREW | LEC Superseded by part number: 79075484 |
| 79019024. | 79019024 | [1] | SPACER | LEC |
| 79019026. | 79019026 | [1] | SEAT/SLOT | LECSEATING |
| 79019027. | 79019027 | [1] | BOX | LECCASE |
| 79019032. | 79019032 | [1] | SCREW | LECDOWEL |
| 79020213. | 79020213 | [1] | SHAFT | LEC |
| 79020215. | 79020215 | [1] | PLATE | LEC |
| 79020348. | 79020348 | [1] | GASKET | LECO-RING |
| 79030940. | 79030940 | [1] | BUSHING | LECSEATING |
| 79031022. | 79031022 | [1] | DISC | LECPLATE |
| 79040285. | 79040285 | [1] | SHAFT | LEC |
| 79040340. | 79040340 | [2] | RING,82mm ID x 90mm OD x 2.38mm Thk | LEC |
| 79045810. | 79045810 | [1] | KIT | LEC-CONSISTING OF |
| 79060609. | 79060609 | [4] | SEALING RING,57.5mm ID x 65.12mm OD x 2.38mm Thk | LEC |
