| 1. |
2383160
|
[2] |
NUT
|
R
Securing nut Vm10
|
| 2. |
7789790
|
[2] |
COMPRESSION SPRING
|
R
Compress.spring
|
| 3. |
8214561
|
[1] |
PIPE
|
R
Lock r.h.
|
| 3. |
8214551
|
[1] |
PIPE
|
R
Lock l.h.
|
| 4. |
614-10040
|
[2] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
CAS
, Start Serial: 04400305 Superseded by part number: 120112
|
| 4. |
614-10035
|
[2] |
BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd
|
CAS
, Serial Range: -04400304 Superseded by part number: 9706704
|
| 5. |
8307180
|
[1] |
FORK
|
R
Deflector stop bei 2,00 M Aufsammler
|
| 5. |
8304620
|
[1] |
FORK
|
R
Deflector stop bei 1,80 M Aufsammler
|
| 6. |
2394370
|
[100] |
SCREW
|
R
Hexagonal screw M 6x 16, 92
|
| 7. |
8171110
|
[2] |
CHAIN (AG)
|
R
Chain 8 x 24x 25 Gl
|
| 8. |
614-10030
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| . . |
2375920
|
[2] |
|
R
Washer 10,5
|
| 9. |
8160491
|
[1] |
PROTECTION PLATE
|
R
Side panel r.h.
|
| 10. |
614-8020
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
43362
|
[8] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[16] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 11. |
8160750
|
[25] |
STRIPPER
|
R
Stripping plate 23
|
| 12. |
08160482
|
[1] |
PROTECTION PLATE
|
R
Side panel l.h.
|
| 13. |
2365100
|
[8] |
SCREW
|
R
Flat head bolt M10x 20x12
|
| . . |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[8] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 14. |
628-12025
|
[8] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd
|
CAS
Hexagonal screw M12x 25
|
| . . |
2361720
|
[8] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[8] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 15. |
8307480
|
[2] |
SUPPORT
|
R
Deflector, Start Serial: 04400305
|
