| 1. |
614-6016
|
[20] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| . . |
825-1406
|
[20] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[20] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 2. |
8170972
|
[2] |
SUPPORT
|
R
Strap
|
| 3. |
8307200
|
[2] |
SHEET
|
R
Guide plate bei 2,00 M Aufsammler
|
| 3. |
8304641
|
[2] |
SHEET
|
R
Guide plate bei 1,80 M Aufsammler
|
| 4. |
6543130
|
[4] |
HINGE
|
R
|
| 5. |
238234N0
|
[4] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 6. |
814-12070
|
[4] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
IH
Hexagonal screw M12x 70 Superseded by part number: 9706717
|
| 7. |
8173940
|
[2] |
CYLINDER ASSY.
|
R
Shock absorber
|
| 8. |
8170510
|
[2] |
ROD
|
R
Guide tube
|
| 9. |
6031050
|
[2] |
SPRING
|
R
Compress.spring
|
| 10. |
239389N0
|
[2] |
WASHER
|
FO
13 x 40 x6 Superseded by part number: 140046
|
| 11. |
2361720
|
[2] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| 12. |
6030980
|
[2] |
EYEBOLT
|
R
Eye bolt
|
| 13. |
369704A1
|
[2] |
SCREW,Hex, M12 x 45mm, Cl 8.8
|
IR
Hexagonal screw M12x 45 Superseded by part number: 9628065
|
| 15. |
8307260
|
[1] |
CHASSIS
|
R
Pick-up frame bei 2,00 M Aufsammler
|
| 15. |
8304420
|
[1] |
CHASSIS
|
R
Pick-up frame bei 1,80 M Aufsammler
|
| 16. |
614-12035
|
[4] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 18. |
1768200
|
[4] |
WASHER
|
R
, Start Serial: 04400305
|
| 19. |
6784402
|
[2] |
SPRING
|
R
Tensioning block, Start Serial: 04400305
|
| 20. |
8018851
|
[2] |
SCREW
|
R
Flat head bolt M10x 25, Start Serial: 04400305
|
| . . |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: 04400305
|
| . . |
98-029441
|
[2] |
WASHER
|
FO
Contact washer A10, Start Serial: 04400305 Superseded by part number: 140045
|
