纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04[004]) - TRANSMISSION GEARS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
648 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10298450. | 10298450 | [2] | GASKET,M12.2 x 18 x 1.5, Alum | MKTGASKET Superseded by part number: 10298460 |
| 70933063. | 70933063 | [2] | RING | CMIRETAINER |
| 79003394. | 79003394 | [1] | GEAR | LECDRIVEN GEAR |
| 79003395. | 79003395 | [1] | GEAR | LECDRIVEN GEAR |
| 79003396. | 79003396 | [1] | GEAR | LECDRIVEN GEAR |
| 79003527. | 79003527 | [1] | SPACER | LEC |
| 79003528. | 79003528 | [1] | SPACER | LEC |
| 79003529. | 79003529 | [1] | SPACER | LEC |
| 79003530. | 79003530 | [1] | RING | LECLOCKRING |
| 79003531. | 79003531 | [2] | HALF-RING | LECHALF RING Superseded by part number: 79037332 |
| 79003556. | 79003556 | [1] | RING | LECTHRUST RING |
| 79004273. | 79004273 | [1] | BALL BEARING,95 mm ID x 182.9 mm OD x 32 mm | LECBEARING Superseded by part number: 79010953 |
| 79009828. | 79009828 | [2] | SCREW,M12 x 1.25 x 63.60mm | LEC |
| 79015276. | 79015276 | [1] | SHAFT | LEC |
| 79015277. | 79015277 | [1] | DISC,50mm ID x 95mm OD x 16mm Thk | LECPLATE |
| 79015278. | 79015278 | [1] | LOCKING PLATE | LECLOCKPLATE |
| 79018906. | 79018906 | [3] | SCREW | LEC Superseded by part number: 79075484 |
| 79023948. | 79023948 | [1] | CYLINDRICAL ROLLER BEARING,75mm ID x 130mm OD x 31mm W | LECBEARING |
| 79041213. | 79041213 | [2] | RING | LECRETAINER Superseded by part number: 70933063 |
| 79045810. | 79045810 | [1] | KIT | LEC-CONSISTING OF |
