| 1. |
2363250
|
[1] |
AXLE PIN
|
R
Threaded pin M 8x10
|
| 2. |
6104470
|
[1] |
RING
|
R
Tension ring 30 Superseded by part number: 6104471
|
| 3. |
2393210
|
[1] |
FLANGE
|
R
Metal flange Pfl 62 N.z.
|
| 4. |
6104480
|
[1] |
BEARING
|
R
Lock collar bear. Pea 206
|
| 5. |
8193250
|
[1] |
TUBE
|
R
Protective tube
|
| 6. |
8137621
|
[8] |
FLANGE
|
R
bearing
|
| 7. |
2381320
|
[16] |
NUT
|
R
Securing nut VM 8 Superseded by part number: 86528579
|
| 8. |
J900227
|
[16] |
BOLT,Hex, M8 x 1.25 x 22mm, Cl 10.9
|
CAS
|
| 9. |
8233710
|
[1] |
SHAFT
|
R
Drive shaft bei 2,00 M Aufsammler
|
| 9. |
8227810
|
[1] |
SHAFT
|
R
Drive shaft bei 1,80 M Aufsammler
|
| 10. |
614-10025
|
[3] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 11. |
98-029441
|
[3] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 12. |
2343040
|
[4] |
WASHER
|
R
|
| 13. |
8221380
|
[20] |
TINE
|
R
Spring tines 24, Aussere Reihen
|
| 14. |
2110320
|
[48] |
SCREW
|
R
Hexagonal screw M10x 25, 44 Superseded by part number: 87015733
|
| . . |
2380060
|
[40] |
NUT
|
R
Securing nut Vm10, 36 Superseded by part number: 86512554
|
| 15. |
8214211
|
[32] |
TINE
|
R
Spring tines 24, Innere Reihen
|
| 16. |
8233740
|
[4] |
BAR
|
R
Tine retainer bei 2,00 M Aufsammler
|
| 16. |
8227850
|
[4] |
BAR
|
R
Tine retainer bei 1,80 M Aufsammler
|
| 17. |
828-10050
|
[12] |
BOLT,Hex, M10 x 1.5 x 50mm, Cl 10.9
|
CAS
Hexagonal screw M10x 50
|
| 18. |
8171680
|
[4] |
LEVER
|
R
|
| 19. |
02139191
|
[4] |
ROLLER
|
R
Guide roller 12 x 35 x 15
|
| 20. |
933073R1
|
[4] |
SNAP RING,M12, Ext
|
IH
Circlip 12x1 Superseded by part number: 11066076
|
| 21. |
8214422
|
[1] |
DISC
|
R
Cam track
|
| 22. |
2378280
|
[3] |
SCREW
|
R
Countersunk bolt M10x 30
|
| . . |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 24. |
930051R1
|
[3] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
IH
Hexagonal screw M10x 40 Superseded by part number: 120112
|
| 25. |
8160331
|
[1] |
BEARING
|
R
shell
|
| 26. |
6160660
|
[1] |
BEARING
|
R
Lock collar bear. Pea 207
|
| 27. |
6160670
|
[1] |
COLLAR
|
R
Set, 35 Superseded by part number: 6160671
|
