凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (021) - PICK-UP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
929 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8304541
|
[2] |
BEARING CARRIER
|
R
Bearing
|
| 2. |
933947R1
|
[2] |
SNAP RING,M78, Ext
|
IH
Circlip 78x2,5 Superseded by part number: 11070776
|
| 3. |
933108R1
|
[4] |
SNAP RING,M62, Int
|
IH
Circlip l 62x2 Superseded by part number: 370012
|
| 4. |
616154R92
|
[4] |
BEARING, ROLLER, CYL,16 mm
|
IH
Grvd.ball bearing 6206 2rs Superseded by part number: 84356151
|
| 5. |
8191681
|
[2] |
BUSHING
|
R
|
| 6. |
8307140
|
[1] |
WORM
|
R
Auger r.h. bei 2,00 m Aufsammler
|
| 6. |
8304580
|
[1] |
WORM
|
R
Auger r.h. 614 lang, bei 1,80 m Aufsammler
|
| 7. |
8307130
|
[1] |
WORM
|
R
Auger l.h. bei 2,00 m Aufsammler
|
| 7. |
8304570
|
[1] |
WORM
|
R
Auger l.h. 614 lang, bei 1,80 m Aufsammler
|
| 8. |
614-12035
|
[4] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| . . |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[4] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
