凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (022) - FEEDER CONTROL ARMS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8300742
|
[1] |
LARGE PIN
|
R
Pin
|
| 2. |
933154R1
|
[4] |
SNAP RING,M80, Int
|
IH
Circlip 80x2,5 Superseded by part number: 300633
|
| 3. |
2385040
|
[1] |
BEARING ASSY
|
R
Grvd.ball bearing 6208-2RS
|
| 4. |
2343900
|
[1] |
WASHER
|
R
Back-up washer S 63x 80
|
| 5. |
7050260
|
[2] |
SPACER
|
R
ring
|
| 6. |
934909R1
|
[1] |
BOLT,Hex, M12 x 1.75 x 65mm, Cl 8.8
|
IH
Hexagonal screw M12x 65 Superseded by part number: 86977776
|
| . . |
238234N0
|
[1] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| . . |
239389N0
|
[1] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 7. |
8300700
|
[2] |
ROD
|
R
Steering rod
|
| 8. |
2392200
|
[1] |
BEARING
|
R
Grvd.ball bearing 6307-2Rs/C3
|
| 9. |
933113R1
|
[1] |
SNAP RING,M35, Ext, Hvy
|
IH
Circlip 35x2,5 Superseded by part number: 87016944
|
| 10. |
2157090
|
[2] |
EYEBOLT
|
R
Joint, head
|
| 11. |
2356060
|
[2] |
NUT
|
R
Hexagonal nut M24x2
|
