凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (023) - FEEDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8300834
|
[1] |
DIPPER
|
R
Swing right
|
| 2. |
933113R1
|
[2] |
SNAP RING,M35, Ext, Hvy
|
IH
Circlip 35x2,5 Superseded by part number: 87016944
|
| 3. |
933154R1
|
[4] |
SNAP RING,M80, Int
|
IH
Circlip 80x2,5 Superseded by part number: 300633
|
| 4. |
2392200
|
[2] |
BEARING
|
R
Grvd.ball bearing 6307-2Rs/C3
|
| 5. |
733-4032
|
[2] |
COTTER PIN,M4 x 32
|
CAS
PIN, SPLIT (COTTER), M4 x 32 Superseded by part number: 412685
|
| 6. |
2444370
|
[2] |
NUT
|
R
Castellated nut M18x1,5
|
| 7. |
2335620
|
[2] |
WASHER
|
R
19 x 40 x6
|
| 8. |
2351820
|
[4] |
CLIP
|
R
Circlip 52x2 Superseded by part number: 33915
|
| 9. |
295109R91
|
[2] |
BALL BEARING
|
IH
Grvd.ball bearing 6205-2RS Superseded by part number: 84188095
|
| 10. |
8300890
|
[1] |
RAKE
|
R
Assist. feed rake mit Pos. 8, 9, 13
|
| 11. |
8300951
|
[1] |
SHAFT
|
R
Axle D 25x1449
|
| 12. |
826-8065
|
[1] |
BOLT,Hex, M8 x 1.25 x 65mm, Cl 10.9
|
CAS
|
| . . |
2381320
|
[1] |
NUT
|
R
Securing nut VM 8 Superseded by part number: 86528579
|
| . . |
98-029447
|
[2] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 13. |
08075771
|
[2] |
HALF-BUSHING
|
R
Shear bush
|
| 14. |
525-5111
|
[2] |
NUT,M22 x 1.5, Cl 8
|
IH
Hexagonal nut M22x1,5
|
| 15. |
2365011
|
[2] |
WASHER
|
R
Safety ring 22
|
| 16. |
8300770
|
[2] |
PIN
|
R
|
| 17. |
8300824
|
[1] |
DIPPER
|
R
Swing left
|
| 18. |
7279630
|
[2] |
SUPPORT
|
R
Ledge
|
| 19. |
8174291
|
[2] |
MUDFLAP
|
R
Rubber strap
|
| 20. |
2369420
|
[1] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 21. |
7851120
|
[1] |
SPACER
|
R
ring
|
| 22. |
8306210
|
[1] |
LARGE PIN
|
R
Pin
|
| 23. |
2335060
|
[1] |
SPRING
|
R
Compress.spring
|
| 24. |
8306201
|
[1] |
LARGE PIN
|
R
Pin
|
| 25. |
2377860
|
[1] |
NUT
|
R
Hexagonal nut M10
|
| 26. |
7785341
|
[1] |
BUTTON
|
R
Ball knob
|
