凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (023[A]) - GRID, FROM SERIAL NO. 04400305 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
350 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-10030
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| . . |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[8] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 2. |
6798370
|
[4] |
SPACER
|
R
Bushing
|
| 3. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 4. |
8308071
|
[2] |
BEARING
|
R
support mit Pos. 2, 3
|
| 5. |
2365520
|
[2] |
SET SCREW
|
R
Threaded pin M10x 8
|
| 6. |
6751290
|
[2] |
BUSHING
|
R
Adjusting ring
|
| 7. |
8310820
|
[1] |
GRILLE ASSY
|
R
Grate
|
