凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (101) - BALE STACKER, HOOK-UP ASSEMBLY (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
987 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-10025
|
[8] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| . . |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[8] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 2. |
8308551
|
[1] |
SUPPORT
|
R
Reinforcement
|
| 3. |
8308600
|
[1] |
SUPPORT
|
R
, Start Serial: 04400305
|
| 3. |
8308630
|
[1] |
SUPPORT
|
R
r.h., Serial Range: -04400304
|
| 5. |
8308663
|
[1] |
SHAFT
|
R
Supporting axle
|
| 6. |
2369420
|
[1] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 7. |
8309611
|
[2] |
SPACER
|
R
Bushing
|
| 8. |
2335261
|
[2] |
PIN
|
R
B20h 11x 55
|
| 9. |
2339930
|
[3] |
PIN
|
R
B20h 11x75x68
|
| 10. |
5001261
|
[4] |
COLLAR
|
R
Adjusting ring
|
| 11. |
8308581
|
[2] |
SUPPORT
|
R
Brace
|
| 12. |
190003871339
|
[4] |
NUT
|
S
Hex, M16 Superseded by part number: 392530
|
| 13. |
2393910
|
[2] |
WASHER
|
R
Contact washer A16
|
| 14. |
614-16050
|
[2] |
BOLT,Hex, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120090
|
| 15. |
814-12030
|
[12] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
CAS
Hexagonal screw M12x 30 Superseded by part number: 9706687
|
| . . |
2361720
|
[12] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[12] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 16. |
8308620
|
[1] |
SUPPORT
|
R
l.h., Serial Range: -04400304
|
| 17. |
2343410
|
[5] |
WASHER
|
R
|
| 18. |
6737490
|
[5] |
SPRING
|
L
clip
|
| 19. |
8308644
|
[2] |
SUPPORT
|
R
Brace
|
| 20. |
2356671
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 6 x 45a
|
| 21. |
8311150
|
[1] |
FOOT
|
R
Stand
|
| 22. |
6656660
|
[1] |
AXLE PIN
|
R
Spring clip
|
| 23. |
8082660
|
[1] |
LEVER
|
R
Fuse lever
|
