纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.12[001]) - REVERSER CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
155 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 586707. | 586707 | [1] | SCREW | MOD |
| 4982514. | 4982514 | [1] | CABLE TIE | LECSTRAP Superseded by part number: 87615202 |
| 10733401. | 10733401 | [3] | COTTER PIN | MKTSPLIT PIN Superseded by part number: 10734401 |
| 10734401. | 10734401 | [3] | COTTER PIN,M2 x 22 | TTFPIN, SPLIT, (COTTER), M2 x 22 |
| 10736401. | 10736401 | [1] | COTTER PIN | LECSPLIT PIN |
| 16105621. | 16105621 | [3] | SLOTTED NUT,M8 x 1.25, Cl 10 | LECNUT |
| 76003007. | 76003007 | [1] | BOOT | LEC |
| 79005331. | 79005331 | [1] | SPRING | LEC |
| 79005332. | 79005332 | [1] | PIN | LEC Superseded by part number: 79024745 |
| 79009863. | 79009863 | [1] | BRACKET | LEC |
| 79012902. | 79012902 | [1] | LINK | LEC Superseded by part number: 79024815, 79024809 |
| 79012969. | 79012969 | [1] | TRACK ROD END ASSY | LECLEVER |
| 79013422. | 79013422 | [1] | CABLE TIE,145mm L | LECSTRAP, CABLE, 145mm L |
| 79016934. | 79016934 | [2] | SPRING | LEC |
| 79016935. | 79016935 | [1] | SHAFT | LEC |
| 79024745. | 79024745 | [1] | PIN | LEC |
| 79024809. | 79024809 | [1] | LINK | LEC |
| 79034816. | 79034816 | [1] | SHAFT | LEC |
