纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.17[001]) - OIL FILTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1012 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 590390. | 590390 | [1] | SNAP RING | LECRETAINING RING |
| 591426. | 591426 | [1] | SPRING | LEC |
| 591431. | 591431 | [1] | BASE PLATE | LECBOTTOM PLATE |
| 591432. | 591432 | [1] | | NNA Superseded by part number: NLS, NLS, NNA591432 |
| 591433. | 591433 | [1] | RING | LECTHRUST RING Superseded by part number: 2978354, 2978354, LEC591433 |
| 10516871. | 10516871 | [4] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 12164721. | 12164721 | [4] | NUT,M10 x 1.25, Cl 10 | TTF |
| 13401875. | 13401875 | [1] | SEAL | MKTLOCKRING Superseded by part number: 13401876 |
| 13449730. | 13449730 | [4] | STUD | LEC |
| 14467081. | 14467081 | [1] | GASKET | LECO-RING Superseded by part number: 14457981 |
| 79004597. | 79004597 | [1] | COVER | LEC |
| 79004598. | 79004598 | [1] | SPRING | LEC |
| 79010563. | 79010563 | [1] | ENGINE OIL FILTER | LECFILTERING ELEMENT Superseded by part number: 79032093 |
| 79032093. | 79032093 | [1] | ENGINE OIL FILTER | LECFILTERING ELEMENT Superseded by part number: 1930779 |
