纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.18[001]) - CONVERTER HEAT-EXCHANGER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
377 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4725316. | 4725316 | [1] | HEAT EXCHANGER | LEC |
| 4989940. | 4989940 | [1] | BRACKET | LEC |
| 11198071. | 11198071 | [4] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 11198671. | 11198671 | [6] | BELLEVILLE WASHER,Belleville, M13 | MKTLOCKWASHER Superseded by part number: 17091174 |
| 15540521. | 15540521 | [4] | SCREW,Hex, M12 x 1.25 x 35mm, Cl 8.8, Full Thd | TTF Superseded by part number: 15540534 |
| 15540621. | 15540621 | [2] | SCREW,Hex, M12 x 1.25 x 40mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M12 x 1.25 x 40, 5.8, Full Thd Superseded by part number: 15540624 |
| 16100811. | 16100811 | [4] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
