凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (103) - BALE STACKER, INTERMEDIATE CHUTE (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
190003871339
|
[2] |
NUT
|
S
Hex, M16 Superseded by part number: 392530
|
| 2. |
2393910
|
[2] |
WASHER
|
R
Contact washer A16
|
| 3. |
2343370
|
[2] |
WASHER
|
R
|
| 4. |
8308922
|
[2] |
SPACER
|
R
Bushing
|
| 5. |
2343690
|
[2] |
WASHER
|
R
, Start Serial: 04400305
|
| 6. |
2354080
|
[2] |
SCREW
|
R
Flat head bolt M16x 70
|
| 7. |
8308123
|
[1] |
SLIDE
|
R
Chute
|
| 8. |
2112890
|
[2] |
REFLECTOR
|
R
Rear reflector
|
| 9. |
8165420
|
[2] |
SLAT
|
R
Glide slat
|
| 10. |
614-8025
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 11. |
5221650
|
[2] |
GRIP
|
R
Att.clip spring
|
| 12. |
8307992
|
[1] |
EXTENSION
|
R
|
| 13. |
9549820
|
[6] |
BUSHING
|
R
Synthetic bush
|
| 14. |
2380600
|
[2] |
WASHER
|
R
|
| 15. |
8309151
|
[3] |
ROLL
|
R
er
|
| 16. |
814-8055
|
[6] |
BOLT,Hex, M8 x 1.25 x 55mm, Cl 8.8
|
CAS
Superseded by part number: 16044321
|
| . . |
2381320
|
[6] |
NUT
|
R
Securing nut Vm 8 Superseded by part number: 86528579
|
| 17. |
8311070
|
[1] |
SHAFT
|
R
|
| 18. |
6737490
|
[2] |
SPRING
|
L
clip
|
