凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (104) - BALE STACKER, BALE BRAKE (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
668 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-10030
|
[6] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8, - bis Nr. .....215 Superseded by part number: 43140
|
| . . |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
- bis Nr. .....215 M10, Cl 8
|
| . . |
98-029441
|
[6] |
WASHER
|
FO
Contact washer A10, - bis Nr. .....215 Superseded by part number: 140045
|
| 2. |
8311210
|
[3] |
STAY
|
R
Brace - bis Nr. .....215
|
| 3. |
8311370
|
[1] |
RETAINER
|
R
Brake plate - ab Nr. .....216
|
| . . |
8311010
|
[1] |
RETAINER
|
R
Brake plate - bis Nr. .....215
|
| 4. |
732-4025
|
[2] |
COTTER PIN,M4 x 25
|
CAS
Split pin 4 x 22, - bis Nr. .....215
|
| 5. |
2368400
|
[2] |
WASHER
|
R
- bis Nr. .....215
|
| 6. |
02335820
|
[2] |
PIN
|
R
B12h11x 35x4, - bis Nr. .....215
|
| 7. |
8310961
|
[1] |
CHASSIS
|
R
Frame - bis Nr. .....215
|
| 8. |
8310990
|
[2] |
BAR
|
R
Strap - bis Nr. .....215
|
| 9. |
614-10025
|
[4] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
- bis Nr. .....215 Hex, M10 x 25, 8.8, Full Thd Superseded by part number: 11106231
|
| 10. |
9086870
|
[2] |
SPRING
|
R
Tension spring
|
| 11. |
7510260
|
[2] |
ROD
|
R
Eye bolt
|
| 14. |
9804640
|
[2] |
STOP
|
R
Buffer bumper
|
| 15. |
239393N1
|
[2] |
WASHER
|
FO
Contact washer B 8 Superseded by part number: 322358
|
| 16. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| 18. |
7215340
|
[2] |
SPACER
|
R
window - ab Nr. .....216
|
| 19. |
2368310
|
[2] |
WASHER
|
R
10,5x 25 x2, - ab Nr. .....216
|
| 20. |
2383160
|
[2] |
NUT
|
R
Securing nut Vm10, - ab Nr. .....216
|
