| 1. |
732-5032
|
[4] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 32
|
| 2. |
2342950
|
[8] |
WASHER
|
R
2,0 mm
|
| . . |
2342340
|
[1] |
WASHER
|
R
1,0 mm
|
| 3. |
2369420
|
[10] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 4. |
6496940
|
[4] |
CYLINDER END CAP
|
R
Bearing
|
| 5. |
614-6020
|
[12] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[12] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[12] |
WASHER
|
R
Contact washer Ers.d.2393860 Superseded by part number: 86588450
|
| 6. |
6100971
|
[4] |
SCREW
|
R
Flat head bolt M 8x 16
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 7. |
8309281
|
[1] |
SUPPORT
|
R
Bearing plate l.h linke Seite
|
| . . |
8309291
|
[1] |
SUPPORT
|
R
Bearing plate r.h rechte Seite
|
| 8. |
931171R1
|
[4] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
| 9. |
614-10025
|
[4] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| . . |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[4] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 10. |
8121260
|
[2] |
BEARING
|
R
Flang.bearing cpl
|
| 11. |
0085610
|
[2] |
SPACER
|
R
Bushing
|
| 12. |
2365520
|
[2] |
SET SCREW
|
R
Threaded pin M10x 8
|
| 13. |
5034141
|
[2] |
COLLAR
|
R
Adjusting ring
|
| 14. |
0085590
|
[4] |
SPACER
|
R
Bushing
|
| 15. |
8309372
|
[1] |
DOOR
|
R
l.h. linke Seite
|
| . . |
8309382
|
[1] |
DOOR
|
R
r.h. rechte Seite
|
| 16. |
2383160
|
[4] |
NUT
|
R
Securing nut Vm 10
|
| 17. |
614-10055
|
[4] |
BOLT,Hex, M10 x 1.5 x 55mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 73161469
|
| 18. |
9162328
|
[4] |
SPRING
|
R
Tension spring
|
| 19. |
8311100
|
[1] |
DOOR
|
R
l.h. linke Seite
|
| . . |
8311110
|
[1] |
DOOR
|
R
r.h. rechte Seite
|
| 20. |
8309460
|
[2] |
LEVER
|
R
|
| 21. |
838-5850
|
[2] |
LOCK PIN,M8 x 50, Slotted
|
CAS
Tensioning M8 x 50, Slotted Superseded by part number: 412689
|
| 22. |
932183R1
|
[2] |
LOCK PIN,M5 x 50, Slotted
|
IH
Tensioning pin 5 x 50a Superseded by part number: 84024216
|
| 24. |
5233050
|
[4] |
HALF-BUSHING
|
R
Guide bushing 225 lg
|
| 25. |
02139191
|
[4] |
ROLLER
|
R
Guide roller 12 x 35 x 15
|
| 26. |
8180591
|
[4] |
BOLT (SPREADER)
|
R
Pin
|
