凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (106) - BALE STACKER, LOWER FLAP (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
264 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 2. |
6798370
|
[4] |
SPACER
|
R
Bushing
|
| 3. |
614-10030
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| . . |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[4] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 4. |
8308071
|
[2] |
BEARING
|
R
support mit Pos. 2
|
| 5. |
8307823
|
[1] |
CHASSIS
|
R
Cover
|
| 6. |
238234N0
|
[2] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 7. |
6716970
|
[4] |
BUSHING
|
R
Synthetic bush
|
| 8. |
8308051
|
[2] |
SHIFTER ROLLER
|
R
Roller mit Pos. 7
|
| 9. |
8307872
|
[2] |
SPACER
|
R
Sleeve
|
| 10. |
931170R1
|
[2] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 8.8
|
IH
Hexagonal screw M12x 80 Superseded by part number: 43158
|
| 11. |
814-8055
|
[8] |
BOLT,Hex, M8 x 1.25 x 55mm, Cl 8.8
|
CAS
Superseded by part number: 16044321
|
| . . |
2381320
|
[8] |
NUT
|
R
Securing nut Vm 8 Superseded by part number: 86528579
|
| . . |
98-029447
|
[16] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 12. |
9549820
|
[8] |
BUSHING
|
R
Synthetic bush
|
| 13. |
8309151
|
[4] |
ROLL
|
R
er
|
| 14. |
8311120
|
[1] |
LARGE PLATE
|
R
Balance plate 1 mm
|
