凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (107) - BALE STACKER, RETAINER (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1026 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8309312
|
[2] |
GUIDE
|
R
Spring guide
|
| 2. |
8309300
|
[2] |
SPRING
|
R
Compress.spring
|
| 3. |
2330310
|
[2] |
WASHER
|
R
13 x 62 x 6
|
| 4. |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| 5. |
6296100
|
[2] |
ROD
|
R
Threaded spindle
|
| 6. |
2365690
|
[2] |
CLEVIS
|
R
Fork head G12x48
|
| 7. |
02335820
|
[2] |
PIN
|
R
B12h11x 35x4
|
| 8. |
732-4025
|
[2] |
COTTER PIN,M4 x 25
|
CAS
Split pin 4 x 22
|
| 9. |
2351242
|
[2] |
WASHER
|
R
13
|
| 10. |
6020650
|
[4] |
BALL JOINT
|
R
Angular joint
|
| 11. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
8308530
|
[2] |
ROD
|
R
Threaded rod
|
| 13. |
98-029441
|
[4] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 15. |
8308431
|
[4] |
LEVER
|
R
Shift lever
|
| 16. |
8308523
|
[2] |
DRIVE SHAFT
|
R
Shaft
|
| 17. |
02356652
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin
|
| 18. |
932335R1
|
[4] |
COTTER PIN,3.5mm OD x 36mm L, Slotted
|
IH
Tensioning pin 3,5 x 36a
|
| 19. |
8309620
|
[2] |
SPRING
|
R
|
| 20. |
2339930
|
[2] |
PIN
|
R
B20h 11x75x68
|
| 21. |
2342950
|
[2] |
WASHER
|
R
|
| 22. |
2377390
|
[2] |
AXLE PIN
|
R
Split pin 4 x 45
|
| 24. |
2368310
|
[4] |
WASHER
|
R
10,5 x 25 x 2
|
| 25. |
6321330
|
[4] |
BOLT (SPREADER)
|
R
Pin B10a12x 28
|
| 26. |
8308511
|
[4] |
LARGE PLATE
|
R
Strap
|
| 27. |
8309340
|
[2] |
LARGE PLATE
|
R
Retainer
|
